QWD80ES
3" WATER TRANSFER PUMP -DIESEL
QWD80ES
The QWD80ES is a high-performance 3” diesel water transfer pump designed for large-scale fluid transfer. Powered by a 6.0HP diesel engine, it offers a maximum head of 28 meters and a capacity of 60m³/hr. With an 80mm suction and discharge port, it ensures efficient fluid intake and delivery. The pump features a quick self-priming time of less than 120 seconds, making it ready for use in no time. The air-cooled, 4-stroke diesel engine provides dependable power, and with electric and recoil start options, as well as a 3.5L fuel tank, it’s built for long-lasting performance in demanding conditions.
Features:
Suction: 80mm for reliable water intake.
Discharge Port Dia: 3” (80mm) for efficient fluid delivery.
Max Head: 28m, providing reliable pressure for water transfer.
Max Capacity: 60m³/hr for high-efficiency fluid transfer.
Max Suction Head: 8m, allowing for water intake from greater depths.
Self Priming Time: <120s for fast and efficient priming.
Engine Type: Air-cooled, 4-stroke Diesel for durability and long service life.
Engine Continuous Output: 6.0HP at 3600 RPM for reliable performance.
Electric & Recoil Start: Battery included for easy starting.
Engine Fuel Tank: 3.5L for extended operation.
Packing Dimensions: 56 x 51 x 62cm for easy storage and transport.
Weight: 51kg for easy handling.
Specifications:
Suction: 80mm
Discharge Port Dia: 3” (80mm)
Max Head: 28m
Max Capacity: 60m³/hr
Max Suction Head: 8m
Self Priming Time: <120s
Engine Type: Air-cooled, 4-stroke Diesel
Engine Continuous Output: 6.0HP; 3600 RPM
Engine Fuel Tank: 3.5L
Weight: 51kg
Packing Dimensions: 56 x 51 x 62cm
