QWP100

QWP100

The QWP100 is a high-capacity 4” transfer pump designed for demanding fluid transfer applications. Powered by an 8.0HP engine, it provides a maximum head of 30 meters and a capacity of 96m³/hr for efficient high-volume fluid delivery. With a 100mm suction and discharge port, the pump ensures optimal intake and discharge performance. Its self-priming time of 30 seconds allows for quick and easy startup. The air-cooled, 4-stroke OHV25 engine delivers reliable power and durability, and with the oil alert system and 3.6L fuel tank, the pump operates efficiently and reliably for extended periods.

Features:

• Suction: 100mm for reliable water intake.

• Discharge Port Dia: 4” (100mm) for effective fluid delivery.

• Max Head: 30m, providing adequate pressure for fluid transfer.

• Max Capacity: 96m³/hr for high-volume fluid delivery.

• Max Suction Head: 7m, allowing for water intake from greater depths.

• Self Priming Time: 30S/4m for fast and efficient priming.

• Engine Type: Air-cooled, 4-stroke, OHV25 for optimal power and durability.

• Engine Continuous Output: 8.0HP at 3600 RPM for reliable performance.

• Engine Fuel Tank: 3.6L for extended operation.

• Fitted with Oil Alert: Protects the engine during operation.

• Packing Dimensions: 52 x 42 x 49cm for easy storage and transport.

• Weight: 26kg for easy handling.

Specifications:

• Suction: 100mm

• Discharge Port Dia: 4” (100mm)

• Max Head: 30m

• Max Capacity: 96m³/hr

• Max Suction Head: 7m

• Self Priming Time: 30S/4m

• Engine Type: Air-cooled, 4-stroke, OHV25

• Engine Continuous Output: 8.0HP; 3600 RPM

• Engine Fuel Tank: 3.6L

• Weight: 26kg

• Packing Dimensions: 52 x 42 x 49cm
